Product Details:
|
| Name: | Truck Oil Seal | Material: | NBR Or Customized |
|---|---|---|---|
| Applition: | Freightliner Trailer | Size: | OD5.753*ID4.375* W1.00 Inch |
| Ref. NoStructure: | 43753 | Color: | Black Or Customized |
| Package: | Inner Bag+outer Box | Heat Resistance: | -40℃-+300℃(depends On Material) |
| High Light: | 5.753*ID4.375* W1.00 mm Truck Oil Seal,43753 Truck Oil Seal,Truck Oil Seal for Freightliner Trailer |
||
Truck Oil Seal Name:
43753 Truck Oil Seal Inch Size OD5.753*ID4.375* W1.00mm for Freightliner Trailer
Truck Oil Seal Description:
|
Product Name |
Truck Oil Seal |
|
Size |
OD5.753*ID4.375* W1.00mm inch |
|
Applition |
Freightliner Trailer |
|
Materials |
NBR, HNBR, EPDM, SILICONE, VITON, FLS, FFPM, PTFE |
|
Temperature |
NBR(-40~120°C),FFKM(-20~320°C) |
|
Feature |
Resistance to high pressure, oil, weather, abrasion, solvent, high temperature, abrasion resistant, aging resistant, insulation, acid and alkaline resistant |
|
Certification |
ISO 9001:2008 SGS Testing Report |
|
Hardness |
30-90 shores A |
|
Color |
Red,Black,White, blue, green,Clear,etc |
|
Size |
111x146x26.5 |
|
Sample Time |
If in stock, within 3 days after payment |
|
Delivery Time |
10-20 days by shipping after final payment |
|
Shipping |
By Ships/Air |
|
Customized |
OEM & ODM are welcomed |
|
Packing |
Plastic bag&carton box or according to your requirements |
| Species |
Oil resistance |
Weather resistance |
Wear resistance |
The lowest Temperature |
The highest Temperature |
Features |
| FKM | optimal | optimal | optimal | -40 | 250 | It has excellent heat resistance, oil resistance and chemical resistance, and is the best balanced rubber for oil seal. |
| VMQ | good | optimal | good | -60 | 225 | It has excellent heat resistance, cold resistance and weather resistance. |
| ACM | optimal | optimal | optimal | -35 | 150 | The heat resistance is better than nitrile butadiene rubber, it has excellent oil resistance to internal combustion engine, gear oil, torque converter oil, etc. |
| AEM | good | optimal | optimal | -40 | 175 | It has good oil resistance and heat resistance, better than acrylic gum, slightly worse than silica gel, but good weather resistance. |
| HNBR | optimal | good | optimal | -40 | 150 | Heat resistance, oil resistance, better weather resistance than nitrile butadiene rubber. |
| NBR | optimal | good | optimal | -40 | 125 | Mineral oil, good wear resistance, widely used in oil seals. |
| EPDM | poor | optimal | good | -40 | 125 | Good water resistance, polar solvent resistance, inorganic drug resistance and weather resistance, but poor oil resistance. |
| PTFE | optimal | optimal | optimal | -65 | 260 | Oil seal material with the best heat resistance, water resistance, chemical resistance, weather resistance and low friction coefficient. |
|
Type |
Inch.Size |
Type |
Inch. Size |
Type |
Inch. Size |
|
Axle |
1.000*1.752*0.641 |
Axle |
3.875*5.690*0.927 |
Axle |
4.250*6.250*1.375 |
|
Axle |
1.063*2.000*0.615 |
Axle |
3.875*5.691*0.938 |
Axle |
4.250*6.254*1.250 |
|
Axle |
1.750*2.500*0.690/0.743 |
Axle |
3.875*5.696*0.875 |
Axle |
4.375*5.748*0.605 |
|
Axle |
2.225/2.375*3.125*0.6/0.7 |
Axle |
3.875*5.696*0.875 |
Axle |
4.375*5.751*0.945 |
|
Axle |
2.250*3.000*0.800 |
Axle |
3.938*5.505*0.750 |
Axle |
4.375*5.751*1.016 |
|
Axle |
2.250*3.251*0.689 |
Axle |
3.999*5.747*0.960 |
Axle |
4.375*5.763*0.930 |
|
Axle |
2.250*3.251*0.740 |
Axle |
4.000*5.126*1.047 |
Axle |
4.375*5.884*0.825 |
|
Axle |
2.500*3.500*0.500 |
Axle |
4.000*5.375*1.000 |
Axle |
4.375*5.905*1.000 |
|
Axle |
2.750*3.779*0.762 |
Axle |
4.000*5.625*0.605 |
Axle |
4.375*6.003*1.047 |
|
Axle |
2.875*3.625*0.472 |
Axle |
4.000*5.626*0.688 |
Axle |
4.375*6.251*0.605 |
|
Axle |
2.875*3.875*0.500 |
Axle |
4.000*5.626*0.700 |
Axle |
4.500*5.374*0.905 |
|
Axle |
3.437*4.755*0.642/0.720 |
Axle |
4.000*5.750*0.928 |
Axle |
4.500*5.750*0.960 |
|
Axle |
3.437*4.755*0.699 |
Axle |
4.000*5.750*1.068 |
Axle |
4.500*5.876*0.984 |
|
Axle |
3.438*4.757*0.700 |
Axle |
4.000*5.754*1.079 |
Axle |
4.625*5.999*0.840 |
|
Axle |
3.438*4.757*0.859 |
Axle |
4.000*5.757*0.866 |
Axle |
4.606*6.311*1.141 |
|
Axle |
3.500*4.547*0.900 |
Axle |
4.000*5.757*0.930 |
Axle |
4.625*6.001*0.912 |
|
Axle |
3.500*4.841*0.919 |
Axle |
4.000*5.757*0.930 |
Axle |
4.625*6.001*1.000 |
|
Axle |
3.500*4.842*0.903 |
Axle |
4.125*5.375*0.605 |
Axle |
4.625*6.006*0.846 |
|
Axle |
3.500*4.842*0.904 |
Axle |
4.250*6.000*0.637 |
Axle |
4.625*6.622*1.093 |
|
Axle |
3.500*4.842*0.925 |
Axle |
4.250*6.000*0.680 |
Axle |
4.750*6.250*0.813 |
|
Axle |
3.574*4.757*0.548 |
Axle |
4.250*6.000*0.750 |
Axle |
4.750*6.308*1.115 |
|
Axle |
3.625*4.810*0.921 |
Axle |
4.250*6.000*0.750 |
Axle |
4.765*6.251*0.605 |
|
Axle |
3.625*4.810*4.823*0.921 |
Axle |
4.250*6.000*0.766 |
Axle |
4.765*6.311*1.078 |
|
Axle |
3.875*5.126*0.605 |
Axle |
4.250*6.000*1.000 |
Axle |
4.766*6.001*1.063 |
|
Axle |
3.875*5.129*0.844 |
Axle |
4.250*6.008*1.142 |
Axle |
4.765*6.311*1.115 |
|
Axle |
3.875*5.376*0.905 |
Axle |
4.250*6.008*0.974 |
Axle |
4.766*6.311*1.125 |
|
Axle |
3.875*5.500*0.938 |
Axle |
4.250*6.048*0.680 |
Axle |
4.767*6.308*1.420 |
|
Axle |
3.875*5.685*0.685/0.920 |
Axle |
4.250*6.250*1.188 |
Axle |
4.875*5.999*0.625 |
|
Axle |
3.875*5.690*0.875 |
Axle |
4.250*6.250*1.300 |
Axle |
4.875*6.373*0.921 |
