Product Details:
|
| Color: | Brown, Black,Blue,Green Or Depends On Requirments | Material: | NBR+PTFE 、 , Rubber, Steel,FKM,FPM |
|---|---|---|---|
| Application: | Machine, Valves, Engine, Shaft, Cylinder | Size: | Custom Size, Standard Size, All, 80x100x10mm, At Least 4000 Kinds Of Size |
| Feature: | Oil Resistance, Corrosion Proof, Sealing Performance, Factory And Home, Heat-Resisitant | Oem: | Aviable, OEM Is Welcomed, Acceptable, Highly Welcomed, |
| High Light: | high temperature oil seals,high pressure oil seal |
||
Product Name:Single lip Tb type Oil Seal, High Quality Material80x100x10mm
Raw material and equipments:
1. We have unique production technology and advanced production equipment;
2. Efficient and precise pre-forming machines have high production efficiency and high speed, meanwhile greatly reduce the waste of production raw materials, and are more efficient and energy-saving;
3. All oil seal vulcanizing machines use vacuum vulcanizing machines and composite molds, which truly achieve high efficiency, high environmental protection, low loss, low waste, and greatly reduce production costs;
| Different Type of Oil Seals | ||||
| Type | Material | Lip | Spring | Feature |
| TC | NBR & FKM | Double Lips | Single | Metal Coverd Rubber |
| TB | NBR | Double Lips | Single | Metal Case |
| TA | NBR | Double Lips | Single | Metal Case |
| sc | NBR & FKM | Single | Single | Double Metal Shell |
| SB | NBR | Single | Single | Metal Case |
| SA | NBR | Single | Single | Double Metal Shell |
| Dc | NBR | Double Lips | Double | Double Springs |
| vc | NBR & FKM | Single | Without | Metal Coverd Rubber |
| VB | NBR | Single | Without | Metal Case |
| Tcv | NBR | Double Lips | Single | High Pressure |
| TCN | NBR | Double Lips | Single | High Pressure |
| PTFE | PTFE | Single & Double Lips | Without | Stainless steel |
| HTCL | NBR & FKM | Double Lips | Single | Inside thread L |
| HTCR | NBR & FKM | Double Lips | single | lnside thread R |
Materials of Rubber :
| NBR | Excellent resistant to oil, Low temperature resistant,widely used in industrial area |
| EPDM | Excellent resistance to weather and ozone, good resistance to heat, low temperature and chemical |
| NR | High elasticity, good chemical strength |
| CR | Generally good resistance to ozone, aging ,and chemical, good mechanical properties over a wide temperature range |
| SBR | Shock resistance,performance well in adhesion and sealing |
| SILICONE | Widest operating temperature range, performance stably in high and low temperature,widely use in food sealing area |
| VT/FKM | Excellent resistance to high temperature and a broad range of chemical, permeability and compression set are excellent |
| HNBR | Thermal stability and oxidation resistance |
| IIR | Low permeability rate and good electrical properties |
Material: /FKM/FPM or Customized
