Product Details:
|
| Name: | Oil Seal For Truck | Material: | FKM FPM VITON/Iron |
|---|---|---|---|
| Color: | Brown Or Black | Size: | 127*165.1*16mm |
| Standard Or Nonstandard: | Custom/Standard | Style: | Rotery Oil Seal |
| Package: | Plastic Bag+carton | ||
| High Light: | High Temperature FKM Trailer Oil Seal,127*165.1*16 Trailer Oil Seal,Trailer rotery oil seal |
||
| Product Name | oil seal for truck shaft |
| Truck Patrs | engine oil seal |
| Size | 127*165.1*16mm |
| OEM | 9828-01203 / 90033-11031 |
| Materials | FKM |
| Temperature |
NBR(-40~120°C),FFKM(-20~320°C) Viton(-20~200°C),Silicone (-70~220°C) EPDM(-50~150°C),PU(-40~90°C) |
| Feature | Resistance to high pressure, oil, weather, abrasion, solvent, high temperature, abrasion resistant, aging resistant, insulation, acid and alkaline resistant |
| Certification |
IATF16949:2016 ISO 9001:2008 SGS Quality Testing |
| Hardness | 70-90 shores A |
| Color | Red,Black,White, blue, green,Clear,etc |
| Sample Time |
If in stock, within 3 days after payment If have mold but no stock ,around 10-20days (Depends on order quantity) If need make new mold , aroud 20-40days (Depends on order quantity) |
| Delivery Time |
3-10days by shipping after final payment |
| Shipping | By Ships |
| Customized | OEM & ODM are welcomed |
| Packing | Plastic bag&carton box or according to your requirements |
| Certification | IATF 16949: 2016 |
| Species |
Oil resistance |
Weather resistance |
Wear resistance |
The lowest Temperature |
The highest Temperature |
Features |
| FKM | optimal | optimal | optimal | -40 | 250 | It has excellent heat resistance, oil resistance and chemical resistance, and is the best balanced rubber for oil seal. |
| VMQ | good | optimal | good | -60 | 225 | It has excellent heat resistance, cold resistance and weather resistance. |
| ACM | optimal | optimal | optimal | -35 | 150 | The heat resistance is better than nitrile butadiene rubber, it has excellent oil resistance to internal combustion engine, gear oil, torque converter oil, etc. |
| AEM | good | optimal | optimal | -40 | 175 | It has good oil resistance and heat resistance, better than acrylic gum, slightly worse than silica gel, but good weather resistance. |
| HNBR | optimal | good | optimal | -40 | 150 | Heat resistance, oil resistance, better weather resistance than nitrile butadiene rubber. |
| NBR | optimal | good | optimal | -40 | 125 | Mineral oil, good wear resistance, widely used in oil seals. |
| EPDM | poor | optimal | good | -40 | 125 | Good water resistance, polar solvent resistance, inorganic drug resistance and weather resistance, but poor oil resistance. |
| PTFE | optimal | optimal | optimal | -65 | 260 | Oil seal material with the best heat resistance, water resistance, chemical resistance, weather resistance and low friction coefficient. |
1. The surface roughness of the shaft is in accordance with the provisions of GB1801. The shaft surface in contact with the oil seal should be
ground to a surface roughness Ra0.2 ～ 0.63um and Rmax = 0.8 ~ 2.5um.
2. The diameter tolerance of the shaft shall not exceed h11 according to GB1801.
3. The chamfer width is according to GB13871-92.
4. Surface hardness: The material of the shaft is preferably carbon steel and alloy steel. The recommended hardness is HRC45 or higher. When
the medium is dirty and has contaminated impurities from the outside or the linear speed of the shaft is ≥12m / s, the surface hardness of the
shaft It should be HRC50 ～ 60, and the depth of quenching layer should be ≥0.3mm.
5. The shaft is chamfered at 30 degrees (maximum). There should be no burrs, sharp corners, and spiral processing marks on the chamfer. The
roughness of the chamfered surface Ra ≦ 3.2um. The heat-treated carbonized layer must be polished and removed.
Q1: How long is your delivery time?
A: 3-5days after payment received(public holiday excluded).
Q2: How to make payment?
A: We accept multiple payment method like Bank Transfer, Western Union, Money Gram, Credit Card, Paypal ,L/C and so on.
Q3:Who will pay importing duties?
A: Our quotation does not includes importing cost such as duties. So our customer has to pay these fees according to importing policy of their
country. If our customer has special requirement for the declared value, you can tell us.
Q4:How about your product quality control?
A:We produce strictly according to the standard production process : qualified material--vulcanization--trimming-second vulcanization--quality
inspection.
Q5: What is your advantages?
A:Our products offers excellent quality, reasonable price, good after-sales service & quality assurance.
